网百金刚大功率无线AP，是一款实用的室内无线网络产品，完全由台湾厂商OEM代理生产，功率高达1000mw，易于室内安装，室内传输最远200米，对于办公室的隔墙有良好的穿透性，在50米范围内无线信号可以轻易穿透两到三堵隔墙。网百金刚大功率无线AP是中小企业组建室内无线网络的最合适的选择。
网百金刚大功率无线AP－参数
|
Connector |
One antenna connector dOne LAN port switch + One WAN port dPower jack |
|
Standard |
dIEEE802.11b/g, IEEE802.3af |
|
Frequency Range |
d2.400GHz ~ 2.4835GHz |
|
Number of Selectable Channels |
USA (FCC) 11 channels dEU (ETSI) 13 channels dJapan (TELEC) 14 channels |
|
Modulation Technology |
802.11b: Direct Sequence Spread Spectrum (PBCC, CCK, DQPSK, DBPSK) d802.11g: Orthogonal frequency division multiplexing |
|
Data Rate |
802.11b: 1, 2, 5.5, 11Mbps; auto‐fallback d802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps; auto‐fallback |
|
Output Power (Typical) |
802.11b: 29dBm d802.11g: 24dBm |
|
Sensitivity |
‐73dBm@54Mbps d‐87dBm@11Mbps |
|
Antenna |
dOne detachable Antenna (Male SMA Reverse 2dBi) |
|
Operation Mode |
dAP, Client, WDS, AP+WDS |
|
Security |
d64/128bit WEP, WPA, WPA2, 802.1x, 802.11i, WPS |
|
Operation Temperature |
d0℃~55℃ |
|
Storage Temperature |
d‐20℃ ~ 70℃ |
|
Humidity |
d5% ~ 90% (Non‐condensing) |
|
Coverage Area |
dOpen space over 2500M/11Mbps by 5dBi Omni Antenna |
|
Power Requirement |
d48VDC/0.4A for RJ45 connector, 12VDC/1A for DC jack |
|
Weight |
240g |
|
Dimension |
d165(L) x 118(W) x 27(H)mm |
